Piaggio 267770 Rear Brake Shoes 9″ Wheel – Vespa 50 N L R S Special 1st Series and 90

The Piaggio 267770 rear brake shoes are the original pair for the rear drum of Vespa smallframes with 9-inch wheels: Vespa 50 N, L, R, Vespa 50 S, first series Vespa 50 Special, and Vespa 90. Inner drum diameter 135 mm, width 20 mm, two anchor points. Product code 267770.

✓ Key Features

• Original Piaggio spare part – the same component listed in the catalog for the rear brake of 9″ wheel smallframes
• Complete pair – the package contains both brake shoes, as required for a rear drum
• Exact drum dimensions – 135 mm inner diameter and 20 mm width, with two anchor points
• Light alloy body – ribbed casting, with new, unbedded friction lining
• Cross-reference 090582 – useful when your parts list shows the older number

Technical Specifications

Vehicle Compatibility

The list refers to smallframes with 9-inch wheels and 135 mm rear drums. If in doubt, send us your scooter's frame number and we will verify the correct code.

Who It's Perfect For

This pair of brake shoes is for anyone putting a 1960s or 1970s Vespa 50 or Vespa 90 back on the road and wanting a truly responsive rear brake. It's the part for the restorer rebuilding the rear hub, for the workshop preparing a vintage vehicle for inspection, and for daily Vespa users who've noticed the brake pedal travel has lengthened and the drum no longer bites as it used to.

Frequently Asked Questions

Which Vespas do these brake shoes fit?
The 267770 brake shoes are intended for Vespa smallframes with 9-inch wheels: Vespa 50 in N, L, and R versions, Vespa 50 S, first series Vespa 50 Special with frame V5A2T and V5A3T, and Vespa 90. The decisive reference is the 135 mm rear drum.

Where exactly are they located on the vehicle?
They operate inside the rear brake drum, on the wheel hub. They expand against the inner surface of the drum when the cam actuated by the pedal pushes them, and they rest on two anchor points machined into the brake shoe backing plate. To replace them, the rear wheel must be removed.

Which original references correspond to this code?
The Piaggio code for this pair is 267770. In parts catalogs, the same component also appears with reference 090582, which identifies the identical 9-inch rear brake shoe. If you find either of these numbers in your parts list, this is the correct item.

How many pieces are needed for the rear brake?
Two are needed, and the package contains both: the Vespa's rear drum mounts a pair of opposing brake shoes. By purchasing this item, you have everything necessary to overhaul the rear brake of a vehicle. Return springs and small parts are not included in the supply.

Are these original Piaggio or aftermarket equivalents?
These are original Piaggio spare parts, the same ones the manufacturer lists in the catalog for these Vespas, new and never mounted. They are not aftermarket equivalents: the profile, mating dimensions, and friction lining are those specified by the manufacturer for the 135-millimeter rear drum.

How can I be sure these are the right ones for my Vespa?
The determining factor is the wheel size. These brake shoes are for smallframes with 9-inch wheels and a 135 mm rear drum, while models with 10-inch wheels use different sized brake shoes. If in doubt, send us your frame number and we will verify the code.
